| Machine Details | |||
|---|---|---|---|
| Make | Name | Weber | |
| Model | Name | WSCP - 30 | |
| Mixer | Out Put Capacity | Cu.M/Hr | 30 m3/hr |
| Type of Mixer | Name | Pan Type | |
| Batch Capacity | Cu.M/Minit | 0.7/1.25 | |
| Mixer Motor | HP | 30 hp Bharat Bijlee Make | |
| Bins | Type of Bins | Name | Inline Type |
| Number of Bins | Nos. | 4 Numbers | |
| Bin Capacity | M TON | 8 MT each bin | |
| Admixture Pump | Type | Name | Self Priming |
| Capacity | HP | 0.5 HP | |
| Water Pump | Type | MONO BLOCK CENTRIFUGLE | |
| Capacity | HP | 2 HP | |
| No of Pumps | Nos. | 1 | |
| Aggregate Conveyor details | No of Conveyors | Nos. | 2 |
| Conveyor Motor Capacity | HP | 10 HP + 10 HP Bharat Bijlee MAKE | |
| Sand Vibrator | Capacity | HP | 1 HP |
| No of Vibrators | Nos. | 1 | |
| Cement Feeding | Make | Name | WAM MAKE |
| Type | Name | SCREW CONVEYER | |
| Hopper Capacity | Cu.M | 1000 KG | |
| Length | Meter | 10 MTR | |
| Motor Capacity | HP | 12.5 HP | |
| Cement Weighing and Discharge Details | Capacity | Ton | 500 KG |
| Type of Weighing | HP | LOAD CELL BASE | |
| Type Of Discharge | BUTTERFLY VALVE | ||
| Cement Vibrator | Capacity | HP | 0.5 HP |
| No of Vibrators | Name | 1 | |
| Aggregate Load Cells | Type | Name | S' Type |
| Numbers | Nos. | 4 Numbers | |
| Capacity / Each | Kg | 2000 kg | |
| Cement Load Cell | Type | Name | REGULAR Type |
| Numbers | Nos. | 2 | |
| Capacity / Each | Kg | 500 kg | |
| Water Load Cell | Type | Name | Electronics weight Control |
| Ad Mixture Load Cell | Type | Name | Electronics weight Control |
| Compressor | Motor Capacity | HP | 3 |
| Control Panel Details | Type of Control Panel | Name | Fully Automatic Microcomputer Touch screen plc batching Control with cabin |
| Make of Electrical Components | Name | TC FRANCE / L&T / SNYIDER | |
| Concrete Discharge height | Mtr | 3.8 Mtr. | |
